CE Certificated Double Layer Cotton Core Under Pad Production Line

Ask Lasest Price
Brand Name :	DNW
Model Number :	DNW-UP01
Certification :	CE, UL
Price :	USD $359000-664000
Payment Terms :	L/C,D/A,D/P,T/T
Supply Ability :	50 set/ year
Delivery Time :	150 days

Add to Cart

Product Details
Company Profile

CE Certificated Double Layer Cotton Core Under Pad Production Line

High quality CE Certificated Double layer cotton core good price korean under pad production line

Drive system:

Full servo drive,digital size change,ensure run synchronized at full process.The frontal tape and back sheet using servo positioning cutting to ensure pattern consistent with the phase.

Product size: S: 390*320M: 450*320 L: 500*330XL: 525*330

Control system:

PLC control,HMI operation,LED digital display,graphic digitization control.

Item No.:
DNW-293

Payment:
30% T/T deposit,70% Balance before shipping

Product origin:
China

Color:
Customized

Shipping port:
Xiamen

Lead Time:
About 180days

Price Range:
$423000-$865000/set

Product Details

Subject	Parameter
Overall size(LWH)	28M4M3.6M(For reference only)
Machine size(LWH)	25m2.1m3.3m,based on the product provided by client
Design speed	600pcs/min
Stable speed	450pcs/min
Pass precentage	98%
Work efficiency	90%
Power source	380V,50HZ,(3phase,4lines+ground wire)
Machine capacity	about 300KW
Air pressure	0.6-0.8Mpa
Machine weight	About 70T
Machine color	Customized

Configuration:

1. Product structure:

Up & Down Tissue Fluff core(mix with SAP),ADL,Backsheet,Frontal tape,Topsheet,Leg cuff N.W,S cut Tape,Elastic waistband lamination online.

2. Product size:

S: 390*320M: 450*320 L: 500*330XL: 525*330

3. Control system:

PLC control system,operating on the touch screen,man-machine interface

4.Tension system:

Tension unwinding equipped,constant tension control with buffer system,automatic web guide system,The unwiding system ensure materials stable working at full speed splice,minimize the impact on materials tension force,to reduce the machine stop frequency.

5.Drive system:

Full servo drive,digital size change,ensure run synchronized at full process.The frontal tape and back sheet using servo positioning cutting to ensure pattern consistent with the phase.

6.Safety system:

Safety guard installed at the operating side,with security identifier,emergency stop switch at per segment,Driven side is equipped with the radiator system and safety wire.

7.Packing way:

Auto stacker as customized design(one push two exit)

8.Materials corrective system:

Germany BST automatic web guide system(optional)
